SMART_DONGLE-4G 4G Communication Module (supports 3G, 2G), connected to inverter via USB, compatible with M0/M1/M2/M3/M5 series, supports up to 10 inverters/devices, IP68

The SMART_DONGLE-4G is a 4G LTE communication module designed for seamless integration with Sofar Solar inverters. It enables remote monitoring, data logging, and fault diagnosis via a USB connection, supporting 3G and 2G fallback. Compatible with M0, M1, M2, M3, and M5 series inverters, it can connect up to 10 devices simultaneously. With an IP68 rating, it is built for outdoor durability.

Advantages

Plug-and-play installation via USB ensures quick setup. Real-time data transmission allows for efficient solar system management. The module's IP68 protection guarantees reliable operation in harsh environments.

Suitable for

• Sofar Solar M0, M1, M2, M3, M5 series inverters
• Residential and commercial solar installations requiring remote monitoring
• Systems needing 4G/3G/2G connectivity for data communication

Key specifications

• Network Technology: 4G LTE (backward compatible with 3G, 2G)
• Connectivity Interface: USB
• Compatible Inverter Series: Sofar Solar M0, M1, M2, M3, M5
• Maximum Connected Devices: 10
• Ingress Protection: IP68
• SIM Card Support: Yes
• Antenna Type: Internal
• Power Supply: Via USB from inverter
• Operating Temperature Range: -30°C to +70°C

Recommendations

For optimal performance, ensure a stable 4G signal and use an active SIM card with data plan. The module is designed for outdoor use but should be installed in a location with adequate ventilation.
